Especificaciones: CPU AMD AM4 Socket 3rd Gen AMD Ryzen Processors * Refer to www.asus.com for CPU support list Chipset AMD B550 Memoria 4 x DIMM- Max. 128GB- DDR4 5100(O.C)/4800(O.C.)/4600(O.C)/4400(O.C)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3466(O.C.)/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory 4 x DIMM- Max. 128GB- DDR4 4600(O.C)/4400(O.C)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3466(O.C.)/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory Next Generation AMD Ryzen PRO Processors OptiMem II 3rd Gen AMD Ryzen Processors Dual Channel Memory Architecture ECC Memory (ECC mode) support varies by CPU. * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists). Grficos 1 x DisplayPort 1.2 1 x HDMI 2.1(4K@60HZ) *Graphics specifications may vary between CPU types. Integrated Graphics Processor Soporte Multi GPU Supports AMD 2-Way CrossFireX Technology Slots de Expansin AMD B550 Chipset 1 x PCIe 3.0 x16 (x4 mode) * 3 x PCIe 3.0 x1 1 x PCIe 4.0 x16 (x16 mode) Almacenamiento 1 x M.2_1 socket 3- with M key- type 2242/2260/2280/22110 storage devices support(SATA & PCIe 4.0 x4 mode) AMD B550 Chipset : 1 x M.2_2 socket 3- with M key- type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)* Total supports 2 x M.2 slots and 6 x SATA 6Gb/s ports 6 x SATA 6Gb/s port(s) 3rd Gen AMD Ryzen Processors : Support Raid 0- 1- 10 LAN Intel I225-V 2.5Gb Ethernet ASUS LANGuard Audio - Audio Shielding - Premium Japanese audio capacitors - Audio Cover - Optical S/PDIF in port(s) at back panel ROG SupremeFX8-Channel High Definition Audio CODEC S1220A - SupremeFX Shielding Technology - Dual OP Amplifiers - Impedance sense for front and rear headphone outputs - Supports : Jack-detection- Multi-streaming- Front Panel Jack-retasking - High quality120dBSNR stereo playback outputand113dBSNR recording input - Supports up to 32-Bit/192kHz playback * - Gold-plated jacks * Due to limitations in HDA bandwidth- 32-Bit/192kHz is not supported for 8-Channel audio. Audio Feature : Puertos USB Front USB Port ( Total 6 ) 2 x USB 3.2 Gen 2 port(s)(1 x Type-A +1 x USB Type-C) Rear USB Port ( Total 8 ) 4 x USB 3.2 Gen 1 port(s)(4 x Type-A) 2 x USB 3.2 Gen 1 port(s) 2 x USB 2.0 port(s) 4 x USB 2.0 port(s) Software Features ROG Exclusive Software - RAMCache III - ROG CPU-Z - GameFirst VI - Sonic Studio III + Sonic Studio Virtual Mixer - Sonic Radar III - DTS Sound Unbound - Overwolf - Anti-virus software ASUS Exclusive Software Features Armoury Crate - Aura Creator - Aura Sync - AI Noise Cancelling Microphone AI Suite 3: - PPSU EPU DIGI+ VRM Fan Xpert 4 TurboV EVO - EZ update WinRAR UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode ASUS Special Features Aura Sync - Standard RGB header(s) - Addressable Gen 2 RGB header(s) ASUS Q-Design - ASUS Q-DIMM - ASUS Q-LED (DRAM [yellow]-CPU [red]- VGA [white]- Boot Device [yellow green) - ASUS Q-Slot ASUS Thermal Solution - Aluminum M.2 heatsink ASUS EZ DIY -BIOS FlashBack button -BIOS FlashBack LED -Clear CMOS header -ProCool -Pre-mounted I/O shield - SafeSlot Puertos I/O Traseros 1 x BIOS FlashBack Button(s) 2 x USB 3.2 Gen 2 (1 x Type-A+1 x USB Type-C) 1 x Intel I225-V 2.5Gb Ethernet 4 x USB 3.2 Gen 1 2 x USB 2.0 5 x Gold-plated audio jacks 1 x DisplayPort 1 x HDMI 1 x Optical S/PDIF out ASUS Wi-Fi module (Wi-Fi 802.11 a/b/g/n/ac and Bluetooth v5.0) Internal I/O 1 x M.2 Socket 1 with M key- type 2242/2260/2280/22110 storage devices support(SATA & PCIe 4.0 x4 mode) 1 x M.2 Socket 2 with M key- type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode) 1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s) 1 x Thunderbolt header(s) 6 x SATA 6Gb/s connector(s) 1 x AAFP connector 1 x Thermal sensor connector(s) 1 x CPU Fan connector(s) 1 x CPU OPT Fan connector(s) 3 x Chassis Fan connector(s) 1 x AIO_PUMP connector 2 x Aura RGB Strip Header(s) 1 x Addressable Gen 2 header(s) 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) 1 x 24-pin EATX Power connector(s) 1 x 8-pin ATX 12V Power connector(s) 1 x 4-pin ATX 12V Power connector(s) 1 x System panel(s) 1 x Clear CMOS jumper(s) Accessorios 1 x M.2 SSD screw package(s) 1 x M.2 Rubber Package(s) 1 x ROG Strix stickers 1 x Cable ties pack(s) 1 x Extension cable for Addressable LED 1 x ROG Thank you card Users manual 4 x SATA 6Gb/s cable(s) 1 x Supporting DVD BIOS 256 Mb Flash ROM- UEFI AMI BIOS Capacidad de gestin WOL by PME- PXE Sistema Operativo Windows 10 64-bit Factor de forma 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) ATX Form Factor
